G2 Handheld UHF RFID reader

G2 Handheld UHF RFID reader

179(L)×74.5(W)×150(H)mm, MT6762 8 core CPU, 4 GB RAM+ 64 GB ROM, 5.5 inch LCD (720P) touch screen,  UHF/ HF RFID and 1D/2D barcode suppported,, up to 15 meter read distance, 500 tag/ second inventory rate,  Android 10/13 OS, 4G/3G/2G, Wifi, Bluetooth, GPS supported, 8000 mAh Li-ion battery, ISO18000-6C& EPC Gen2 protocol  compliance

Download Specification

OverviewSpecificationApplicationsSupport

G2 is a industrial leading handheld rfid reader based on Andriod 10/ 13 OS. Configured with MT6762  8 core CPU, 4GB RAM + 64 GB ROM, 5.5“ LCD with touch screen, high performance uhf rfid module and optional NFC and 1D/2D scanner, it can support both UHF, HF and 1D/ 2D barcode scanning with excellent read distance of up to 15 meter and rfid tag inventory speed of 500 tags/second. 4G/3G/2G/ Wifi/ bluetooth wireless communication also enable user to easily and fastly connected into network, which is widely used in retail, warehousing, public assets management, etc.




Main features

•   MT6762 8 core CPU, 1.8 Ghz, 4 GB RAM + 64 GB ROM

•   5.5 " LCDwith touch screen ( 720P), 8000 mAh Li-ion battery

   FCC ( North America)  902~ 928 Mhz,  ETSI ( EU) 865~ 868 Mhz

•   High performance UHF RFID module, 0- 33 dBm RF

•   up to 15 meter read distance, > 500 tags/second inventory speed

   Optional NFC module and 1D/2D barcode engine

   Android 10/ 13 OS, provide Android SDK, APK and source code

   4G/3G/2G, Wifi, Bluetooth, GPS supported

   ISO18000-6C & EPC C1G2 protocol, optional IEC14443A/ B, ISO15693 protocol



Software interface







Model:G2
Physical Characteristics   UHF
Dimensions 179mm(L)×74.5mm(W)×150mm(H)   Frequency US 902- 928 Mhz, EU 865- 868 Mhz
Weight 750g   Protocol ISO18000-6C, EPC C1G2
Display 5.5", 1440 x 720 pixel touch LCD   Antenna 4.65 dBi circular polarized antenna
Touch Panel Multi-touch panel, gloves and wet hands supported   Power 0~33 dBm, software adjustable
Power Device battery: removable 8000mAh rated capacity   Read distance up to 15 meter
  Charing time:< 3 hours, standby time: > 350 hours   Inventory speed > 500 tags/second
Expansion card sl 1* Nano SIM card, 1* TF card, 1* POGO Pin
Communication Interface 4G/3G/2G, Bluetooth 5.0, WIFI, USB Type-C
Speaker >92 db
Keypad Volume +, Volume -, Power on/off button, 2 scan buttons
Sensor Gravity, Light sensor, proximity sensor, Vibration motor


Performance Characteristics   NFC
CPU MT6762 Octa core 2.0GHz   Frequency 13.56 Mhz
RAM+ ROM 4GB+64GB   Protocol ISO14443A/B,  ISO15693
Expansion Memor up to 256 GB Micro SD (TF) card   Read distance 2- 5 cm
OS Android 10.0/ Android 13.0

Wireless

Barcode

WLAN 802.11ac/a/b/g/n/d/e/h/i/j/k/r/v  (2.4G/5G dual-band WIFI)   2D Scan engine N6602-W2
4G/ 3G/ 2G

4G:FDD:B1/B3/B4/B7/B8/B12/B20

TDD:B38/B39/B40/B41

  1D Symbologies UPC, EAN, Code 39, Code 128, Code11,
  3G: WCDMA 850/900/1900/2100MHz     Interleaved 2 of 5, Discrete 2 of 5
  2G: GSM 850/900/1800/1900MHz   2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC- 39,
Bluetooth Bluetooth 5.0 (Support BLE)     Datamatrix, QR code, Micro QR code, Aztec,
GNSS GPS, GLONASS, Beidou     MaxiCode, HanXin


Camera
  Environment
Camera Front camera:2M pixel   Operating Temp -10 C to +50 C
  Rear camera: 13M pixel   Storage Temp -20 C to +60 C
      Humidity 5%- 95% RH, no condensing
      Drop Multiple 1.2 m drops across the operating temperature range
      Tumble 1,000 1.64 ft./0.5 m tumbles (2,000 impacts)
      Waterproof IP65


Accessory





The fashion industry was one of the first retail sales sectors to adopt RFID technology

In recent years, mainly in the USA and Europe, dozens of fashion retailers like Marks & Spencer, Levi’s, Throttleman, American Apparel, Le Coq Sportif, Karstadt, Dillards and Galeria Kaufhof have implemented RFID product identification projects to improve their supply chain processes and retail outlet operations.

For such an industry, experiencing seasonal peaks and handling large volumes of goods, the use of RFID tags in the supply chain offers significant advantages:

-    A major improvement in inventory accuracy and speed, resulting in better supply management, greater on-shelf availability and therefore more sales.A clear illustration of the advantages of RFID is that it enables bulk, ‘on-the-fly’ reading, thereby cutting inventory times by 90% and, at the same time, substantially improving inventory accuracy, as RFID leaves little room for human error and information on the style, size and color of an article can all be stored on the tag.

-   Unprecedented fashion logistics productivity gains can be achieved thanks to improved reception, shipment and inventory processes in manufacturing factories, distribution centers and stores.The simultaneous, contactless and ‘on-the-fly’ reading of hanging articles and articles folded into boxes radically reduces the time spent counting and controlling articles during reception and shipment operations. Because it takes only a few seconds to identify all the articles on a pallet, a rack or in a parcel, our customers are spending 12 times less time checking their goods.

Thanks to RFID technology, today we have easier and abundant life than before. It not only change the way we purchasing, but also change the way of production.   It builds an efficient information highway between the manufacturers and end customers, at one end of highway, manufactures can get instant sales status and make right decision on business, while at the other end, customers can directly get the products details and enjoy the fast purchasing  that high technique brought.

Though there are still some concerns upon the newly emerged RFID technology, however as more successful stories come we believe the bright future of RFID technology will come soon.

Related Products

DescriptionDateDownload
G2 Handheld UHF RFID reader specification.pdf2025-03-06
602 KB
G2 Handheld UHF RFID Reader User Manual-v1.0.pdf2025-03-06
1.1 MB
G2 UHF RFID Reader SDK-En.zip2025-03-06
28.3 MB
