GEE-UR-E81 E series 8 port uhf rfid reader
GEE-UR-E81 is an E series 8 port UHF RFID reader based on Impinj E710 platform. Worked at 865- 868 Mhz/ 902- 928 Mhz with 4 SMA antenna ports, it can read rfid tag at distance up to 25 meter with inventory speed of 1000 tags/second . Typical application: Logistics, Vehicle management and asset tracking.
Main features:
• 180 x 180 x 28 mm, 8x SMA antenna port
• FCC ( North America) 902~ 928 Mhz, ETSI ( EU) 865~ 868 Mhz
• Impinj E710 uhf module, inventory speed: 1000 tags/second
• 0-33 dbm RF output. up to 25 meter read distance
• RS232/485, RJ45, WG, USB, GPIO interface, optional POE, WIFI, 4G interface
• Support Windows, Andriod, Linux system, provide X86 & X64, C++, C#, VB, Delphi, Linux, ARM & Raspberry Pi, Python, NodeJS, QT, JAVA, Arduino, Andriod source code
• CE, FCC compliance
| Physical | |
| Material | Sheet metal enclosure |
| Size | 180mm( L) x 180mm ( W) x28mm (H) |
| Antenna | 8x external SMA antenna port |
| Installation method | Floor mounting |
| Weight | 1.5 kg |
| Protocol | ISO18000-6C & EPCglobal Class I Gen 2 |
| Electrical & RF | |
| Frequency | FCC ( North America) 902~ 928 Mhz, ETSI ( EU) 865~ 868 Mhz |
| UHF module | Impinj E710 |
| RF Power | 0~ 33 dBm ( adjustable by software) |
| Read Distance | up to 20 meter ( 12 dbI antenna) |
| inventory speed | >1000 tags/second |
| Work Mode | Active, answer, Tigger mode |
| Tag buffer | 1000 pcs 96 bit EPC tags |
| RSSI | Support |
| GPIO | Support multi-channel isolated GPIO port, 2 input, 2 output |
| Built-in Relay | 2 built-in relay |
| Communication interface | RS232/485, RJ45, USB, GPIO, Optional POE, WiFI, 4G |
| Other features | |
| SDK | Support X86 & X64, C++, C#, VB, Delphi, Linux, ARM & Raspberry Pi, Python, NodeJS, QT, JAVA, Arduino, Andriod |
| Extented read mode | Password mode, Mask mode, white list |
| Environment | |
| Operating condition | -20 ~ 60 C, 5~ 95% RH, no condensation |
| Storage condition | -5 ~ 45 C, 5~ 95% RH, no condensation |
| Water proof | IP65 |
| Certification | CE, FCC |
| 描述 | 日期 | 下载 |
|---|---|---|
| GEE-UR-E201 E series Modbus UHF RFID Reader Specification.pdf | 2023-09-05 |  1 MB |
| E series UHF RFID reader SDK.zip | 2021-05-18 | 170 MB |
